Dormer-Pramet

Regular length Barrel shape end mill with 3 flutes, diameter 8 mm with 25 mm length of cut, 75 mm overall length, 1 mm full profile radius and 90 mm tangential radius, according to Dormer Pramet standard with a 8 mm plain shank, solid carbide with AlCrN coating, 30° helix and 8° rake angle for copy milling and turn milling in steel and cast steel or cast-iron

Package Quantity: 1

For complete technical specifications, cutting parameters, engineering data, and current availability across distribution centers, refer to the official Dormer-Pramet product page using the link below:

https://dormerpramet.com/p/8030339
