C6-DDNNN-00065-15

C6-DDNNN-00065-15

$465.69 CAD $479.00 CAD
Skip to product information
C6-DDNNN-00065-15
C6-DDNNN-00065-15

Dormer-Pramet

C6-DDNNN-00065-15

Material ID: 7809792

$465.69 CAD $479.00 CAD

C6-DDNNN-00065-15

Turning Toolholder Polygon Shank Coupling ISO D - External

Material ID: 7809792


Double clamp turning tool for holding a 55° rhombus negative insert with an inscribed circle diameter of 12.7 mm, 6.35 mm thick (ISO designation DN.. 1506.. ), neutral hand 62°30' side cutting with straight shank according to ISO 26623 (Polygon Shank Coupling) size C6, with 65 mm protruding length for single and multi-directional copy turning

Package Quantity: 1

For complete technical specifications, cutting parameters, engineering data, and current availability across distribution centers, refer to the official Dormer-Pramet product page using the link below:

https://dormerpramet.com/p/7809792
