Dormer-Pramet

Copy face mill with double negative geometry which utilises 7 of RC.. 10.... single-sided inserts, cutting diameter 66 mm with 27 mm connection bore according to DIN 8030-A, 50 mm protrusion length, through coolant for face milling, copy milling, ramping, helical milling and progressive plunge milling with a maximum depth of cut of 5.0 mm

Package Quantity: 1

For complete technical specifications, cutting parameters, engineering data, and current availability across distribution centers, refer to the official Dormer-Pramet product page using the link below:

https://dormerpramet.com/p/7444338
