Dormer-Pramet

Face mill with double positive geometry which utilises 9 of OE.. 06...., RE.. 16.... or XE.. 06.... single-sided inserts, cutting diameter 5.000 inch with 43° approach angle and 1.500 inch connection bore according to DIN 8030-A, 2.480 inch protrusion length, through coolant for face milling and chamfering with a maximum depth of cut of .130 (.390)"

Package Quantity: 1

For complete technical specifications, cutting parameters, engineering data, and current availability across distribution centers, refer to the official Dormer-Pramet product page using the link below:

https://dormerpramet.com/p/7275032
