Dormer-Pramet

Lever lock turning tool for holding a 80° rhombus negative insert with an inscribed circle diameter of 12.7 mm, 4.76 mm thick (ISO designation CN.. 1204.. ), left hand 95° side and end cutting with off-set shank, 32 mm tool height x 25 mm width x 170 mm long for taper turning, face turning with and without shoulder and longitudinal turning with and without shoulder

Package Quantity: 1

For complete technical specifications, cutting parameters, engineering data, and current availability across distribution centers, refer to the official Dormer-Pramet product page using the link below:

https://dormerpramet.com/p/6756740
